GitHub Actions — Workflow Syntax Reference

Workflow Triggers

Control when a workflow runs.

YAML

on:
  push:
    branches: [main]
  pull_request:
    branches: [main]
  schedule:
    - cron: "0 2 * * *"        ## daily at 2 AM UTC
  workflow_dispatch:            ## manual trigger from the Actions tab
    inputs:
      environment:
        description: "Target environment"
        required: true
        default: "staging"

Parameter Breakdown:

push / pull_request: Restrict with branches: or paths: to avoid running on every commit
schedule: Cron syntax, always evaluated in UTC regardless of repo settings
workflow_dispatch: Adds a manual "Run workflow" button, optionally with input fields

Jobs and Steps

The core structure of a workflow file.

YAML

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-node@v4
        with:
          node-version: "20"
      - run: npm ci
      - run: npm test
      - name: Build production bundle
        run: npm run build

Parameter Breakdown:

uses: Runs a reusable action from the marketplace or another repo
run: Executes a raw shell command on the runner
with: Passes input parameters into an action

Secrets and Environment Variables

Inject configuration without hardcoding values.

YAML

jobs:
  deploy:
    runs-on: ubuntu-latest
    env:
      NODE_ENV: production
    steps:
      - run: echo "Deploying to ${{ env.NODE_ENV }}"
      - run: ./deploy.sh
        env:
          AWS_ACCESS_KEY_ID: ${{ secrets.AWS_ACCESS_KEY_ID }}
          AWS_SECRET_ACCESS_KEY: ${{ secrets.AWS_SECRET_ACCESS_KEY }}

Parameter Breakdown:

secrets.<NAME>: Pulled from repo or org-level Settings → Secrets, never logged in plaintext
env at job level applies to every step; env at step level overrides for that step only
${{ }}: The expression syntax used to reference contexts like secrets, env, and github

Matrix Builds

Run the same job across multiple versions or platforms.

YAML

jobs:
  test:
    runs-on: ${{ matrix.os }}
    strategy:
      matrix:
        os: [ubuntu-latest, macos-latest]
        node-version: [18, 20, 22]
      fail-fast: false
    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-node@v4
        with:
          node-version: ${{ matrix.node-version }}
      - run: npm test

Parameter Breakdown:

strategy.matrix: Generates one job per combination — 2 OS × 3 versions = 6 parallel jobs here
fail-fast: false: Lets every matrix combination finish even if one fails — useful for full test visibility
Matrix values are referenced with matrix.<key> anywhere in the job

Caching Dependencies

Speed up repeat runs by avoiding redundant downloads.

YAML

steps:
  - uses: actions/checkout@v4
  - uses: actions/cache@v4
    with:
      path: ~/.npm
      key: npm-${{ runner.os }}-${{ hashFiles('package-lock.json') }}
      restore-keys: |
        npm-${{ runner.os }}-
  - run: npm ci

Parameter Breakdown:

key: A cache miss triggers a fresh install and a new cache save — tie it to the lockfile hash
restore-keys: Fallback prefixes if the exact key isn't found, partial cache is still faster than none
setup-node@v4 also supports cache: npm built in, simpler for basic cases

Artifacts

Pass files between jobs or save build output.

YAML

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - run: npm run build
      - uses: actions/upload-artifact@v4
        with:
          name: build-output
          path: dist/

  deploy:
    needs: build
    runs-on: ubuntu-latest
    steps:
      - uses: actions/download-artifact@v4
        with:
          name: build-output
          path: dist/
      - run: ./deploy.sh dist/

Parameter Breakdown:

needs: build: Forces the deploy job to wait for build to finish successfully
upload-artifact / download-artifact: The standard way to share files between separate jobs (separate runners)
Artifacts persist after the workflow completes — visible in the Actions run summary

Conditional Execution

Run steps only when specific conditions are met.

YAML

steps:
  - run: echo "Only runs on main"
    if: github.ref == 'refs/heads/main'

  - run: echo "Only on pull requests"
    if: github.event_name == 'pull_request'

  - run: echo "Runs even if a previous step failed"
    if: always()

  - run: ./notify-failure.sh
    if: failure()

Command Parameter Table:

Function	Description
`always()`	Runs regardless of prior step outcome
`failure()`	Runs only if a previous step in the job failed
`success()`	Default behavior — runs only if everything before it passed

Reusable Workflows

Share workflow logic across repos.

YAML

## .github/workflows/deploy.yml — the reusable workflow
on:
  workflow_call:
    inputs:
      environment:
        required: true
        type: string
    secrets:
      DEPLOY_KEY:
        required: true
jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - run: ./deploy.sh ${{ inputs.environment }}

## calling-workflow.yml — in another workflow
jobs:
  call-deploy:
    uses: razorpay/shared-workflows/.github/workflows/deploy.yml@main
    with:
      environment: staging
    secrets:
      DEPLOY_KEY: ${{ secrets.DEPLOY_KEY }}

Parameter Breakdown:

workflow_call: Makes a workflow callable from other workflows, like a function
Secrets must be explicitly passed through — they don't inherit automatically
Pin reusable workflows to a tag or SHA in production, not a moving branch

Docker Build and Push

Build and publish container images from a workflow.

YAML

steps:
  - uses: actions/checkout@v4
  - uses: docker/login-action@v3
    with:
      username: ${{ secrets.DOCKERHUB_USERNAME }}
      password: ${{ secrets.DOCKERHUB_TOKEN }}
  - uses: docker/build-push-action@v6
    with:
      context: .
      push: true
      tags: razorpay/orders-api:${{ github.sha }}
      cache-from: type=gha
      cache-to: type=gha,mode=max

Parameter Breakdown:

cache-from/cache-to: type=gha: Uses GitHub Actions' own cache backend for Docker layer caching
github.sha: Tags the image with the exact commit, far better than relying on latest
docker/login-action: Authenticates before push — must run before build-push-action

Debugging Failed Runs

Get more information out of a failing workflow.

YAML

## Enable step debug logging — set as a repo secret
## ACTIONS_STEP_DEBUG = true

steps:
  - name: Dump GitHub context
    run: echo '${{ toJSON(github) }}'

  - name: SSH into the runner for live debugging
    uses: mxschmitt/action-tmate@v3
    if: failure()

Notes:

ACTIONS_STEP_DEBUG=true as a repo secret unlocks verbose step-by-step logs on every run
toJSON(github) dumps the full event payload — useful when a trigger isn't behaving as expected
action-tmate opens an SSH session into the actual runner, gated to only fire if: failure()
